DURKOPP ADLER 745-34-2 - Checking the Smoother Function

–
Select the required test program with cursor keys “ï”or“ð”.
A black background appears behind the symbol.
–
Press OK to run the selected program.
–
To leave machine parameters press the “RST” key or turn off the
main switch.
7.3.3 Checking the smoother function
This program tests the function of the smoother.
Info line:
Testing smoother
–
Press OK to run the test program.
The symbol appears with the entry fields.
smoother time (t)
smoother velocity (v)
–
Enter the required values for “t” and “v”.
Entry:
Active period: t = 10...1000
Increment: 1 stroke = 0.001 s
Velocity stage: v = 1...15
–
Press the “F5“key.
The smoother runs for the selected period at the set velocity.
–
To leave the test program press function key F1.
