DURKOPP ADLER 745-34-2 - Testing Needle and Center-Blade Activation

7.3.6 Testing needle and center-blade activation
This program tests the activation of the needles and the center blade
with the machine running.
Info line:
Activating needle, center blade
–
Press OK to start the program.
–
Press function key F3:
once to start the sewing drive at 1000 rpm,
a second time to increase the sewing-drive speed to 3000 rpm
and a third time to stop in position 2 (thread lever up)
–
The center blade is switched on and off with function key F4.
–
The needles are switched on and off with function key F5.
–
Press function key F1 to leave the test program.
CAUTION:
Before leaving the program the machine head must be run for a short
time with the needles and center blade switched off
otherwise the next seam will not be properly executed.
64
