DURKOPP ADLER 745-34-2 Programming Instructions

8.2 Stepping motors error messages
Error number Meaning Remedy
Error 2101 Step motor feed clamp timeout reference
- Faulty cable to the reference switch
- Faulty reference switch
- Replace cable
- Replace reference switch
Error 2103 Step motor feed clamp has step loss
- Check seizing of the feed clamp
Error 2152 Step motor feed clamp excess
current
- Replace step motor feed clamp
- Replace control
Error 2153 Step motor feed clamp excess voltage
- Too high mains voltage
Check the mains voltage
Error 2156 Step motor feed clamp overheat
- Step motor feed clamp seized up
- Faulty step motor feed clamp
- Faulty control
- Eliminate seizing
- Replace step motor feed clamp
- Replace control
Error 2201 Step motor corner-blade frames
timeout reference
- Faulty cable to the reference switch
- Faulty reference switch
- Replace cable
- Replace reference switch
Error 2253 Step motor corner-blade frames
excess voltage
- Too high mains voltage
Check the mains voltage
Error 2256 Step motor corner-blade frames overheat
- Step motor corner-blade frames
seized up
- Faulty step motor corner-blade frames
- Faulty control
- Eliminate seizing
- Replace step motor corner-blade frames
- Replace control
Error 2353 Step motor tape feeder excess voltage
- Too high mains voltage
Check the mains voltage
Error 2356 Step motor tape feeder overheat
- Step motor tape feeder seized up
- Faulty step motor tape feeder
- Faulty control
- Eliminate seizing
- Replace step motor tape feeder
- Replace control
Error 2401 - Failure step motor seam-start
corner-blade
Faulty cable to the reference switch
Faulty reference switch
Faulty step motor, seized up.
Error 2501 - Failure step motor seam-end
corner-blade
Faulty cable to the reference switch
Faulty reference switch
Faulty step motor, seized up.
Error 2601 - Failure step motor piping cutter
Faulty cable to the reference switch
Faulty reference switch
Faulty step motor, seized up.
8.3 Operating indicator error messages
Error number Meaning Remedy
Error 3100 Machine Control Voltage
- Temporary mains voltage drop
- Check the mains voltage
Error 3101 Machine Power Voltage
- Temporary mains voltage drop
- Check the mains voltage
Error 3102 Machine Voltage Sewing Motor
- Temporary mains voltage drop
- Check the mains voltage
Error 3103 Machine Voltage Step Motors
- Temporary mains voltage drop
- Check the mains voltage
Error 3107 Machine Temperature
- Vent holes closed
- Ventilation grid soiled
- Check the vent holes
- Clean the ventilation grid
4
89
