7.3.8 Checking the gripper folder without feed clamp (versions B and F only)
This program tests the function of the gripper folder.
The feed clamps remain in their rear end position.
F3 F5
Info line:
Testing gripper folder
–
Press OK to run the test program.
–
Press function key F3.
The gripper folder swivels to the vertical position.
–
Press function key F5.
The gripper folder swivels to the vertical position and descends
onto the material slide plate.
–
For setting purposes, the gripper folder can be swayed to the
vertical position, pivoted and unpressurized above the piping
support table, through the key 9.
–
Press function key F1 to leave the test program.
66
