Input elements DACIII
Input Function Insertion method
element ABDF
S01 Needle-thread monitor left XXXX
S02 Needle-thread monitor right XXXX
S05 Folderdown XXXX
S06 Foldingstationswungin XXXX
S07 Simple piping right X X X
S08 Simple piping left X X X
S09 Knifebracketmonitoring XXXX
S10 Removematerial/ XXXX
cover monitoring
S11 Pressuremonitor XXXX
S12 Right pedal forward XXXX
S14 Left pedal forward XXXX
S15 Left pedal back XXXX
S16 Right pedal back XXXX
S17 Flap scanning 1 XXXX
S20 Flap scanning 2 X X X
S21 Tapecontrol XXXX
S24 Piping knife adjustment reference X X
S111 Residual-thread monitor right XXXX
S101 Feed-device reference XXXX
S102 Seam-startcorner-bladereference XXXX
S110 Residual-thread monitor left XXXX
S100 Sewingmotorreference XXXX
*) Input elements can only be tested by means of the test program 6.3.1 “Adjusting the
looper-thread monitor”
Input elements CAN node 0
Input Function Insertion method
element ABDF
SC001 Seam-start blade-adjustment reference XXXX
SC003 Seam-end blade-adjustment reference XXXX
Input elements CAN node 1
Input Function Insertion method
element ABDF
SC001 Folder on top X X
SC002 Folder on piping table X X
SC003 Folder vertical X X
SC004 Folder inclined X X
76
