Working basis
10 Service Instructions 667 - 00.0 - 04/2016
3.3 Removing the covers
For many types of setting work, you will have to remove the machine cov-
ers first in order to access the components.
This chapter describes how to remove and then refit the individual covers.
The text for each type of setting work then specifies only the cover that
needs to be removed at that particular time.
3.3.1 Tilting and erecting the machine head
To access the components on the underside of the machine, swivel up the
machine head.
Fig. 1: Tilting and erecting the machine head
Tilting the machine head
To tilt the machine head:
1. Tilt the machine head as far as it will go.
Erecting the machine head
To erect the machine head:
1. Erect the machine head.
WARNING
Risk of injury from moving parts!
Crushing possible.
Switch off the machine before removing or
re-placing covers.
