3.6 Setting the handwheel into position
For some settings, the graduated scale on the handwheel has to be moved
to a certain position.
Fig. 10: Setting the handwheel into position
To set the handwheel into position:
1. Turn the handwheel until the specified number on the graduated
scale (1) is next to the marking (2).
(1) - Graduated
scale
(2) - Marking
