Working basis
Service Instructions 667 - 00.0 - 04/2016 13
3.3.4 Removing and placing the valve cover
Fig. 4: Removing and placing the valve cover
Removing the valve cover
To remove the valve cover:
1. Loosen all 4 screws (1).
2. Remove the valve cover (2).
Important
When removing the valve cover, be sure not to pull off any cables.
Placing the valve cover
To place the valve cover:
1. Place the valve cover (2).
2. Tighten all 4 screws (1).
Important
When placing the valve cover, be sure not to pull off any cables.
(1) - Screws (2) - Valve cover
