Working basis
12 Service Instructions 667 - 00.0 - 04/2016
3.3.3 Removing and placing the head cover
Fig. 3: Removing and placing the head cover
Removing the head cover
To remove the head cover:
1. Loosen the screws (1).
2. Remove the head cover (2).
Placing the head cover
To place the head cover:
1. Place the head cover (2).
2. Tighten the screws (1).
(1) - Screws (2) - Head cover
