Sewing feet
Service Instructions 667 - 00.0 - 04/2016 53
11 Sewing feet
The two adjusting wheels (3) on the machine arm determine how high the
presser foot (1) and feeding foot (2) are raised during the sewing process.
The left adjusting wheel determines the normal sewing foot stroke.
The right adjusting wheel determines the elevated sewing foot stroke.
The elevated sewing foot stroke must not be lower than the normal sewing
foot stroke.
Fig. 34: Sewing feet
NOTICE
Property damage may occur!
Machine can be damaged if the adjusting wheels are forced.
Do not attempt to use force to set a smaller sewing foot stroke at the
right adjusting wheel.
5
6
4
1
2
9
1
2
3
(1) - Presser foot
(2) - Feeding foot
(3) - Adjusting wheels for the sewing foot
stroke
