Position of the hook and needle
52 Service Instructions 667 - 00.0 - 04/2016
3. Loosen the screw (2) of the needle bar (1).
4. Move the height of the needle bar (1) such that the hook tip (4) is in
the middle of the lower third of the groove for the needle.
Important
When doing so, take care not to twist the needle to the side.
The groove (3) must face toward the hook.
5. Tighten the screw (2) for the needle bar (1).
6. Remove the lock ( p. 16).
Order
Then check the following setting:
• Position of the needle guard ( p. 51)
