Dynapac CC1000 User Manual

Maintenance - 2000h
4812160801_D.pdf2018-12-17
Hydraulic fluid filter - Change
Fig. Engine compartment, left side
1. Hydraulic fluid filter
1
Remove the filter (1) and deliver to special waste
handling. This is a single-use filter and cannot be
cleaned.
Remove the filter (1) and deliver to special waste
handling. This is a single-use filter and cannot be
cleaned.
Thoroughly clean the filter holder sealing surface.
Apply a thin coat of fresh hydraulic fluid to the rubber
gasket on the new filter.
Screw the filter on by hand, firstly until the filter gasket
makes contact with the filter base. Then rotate a
further ½ turn.
Do not over-tighten. The seal can be damaged.Do not over-tighten. The seal can be damaged.
Start the engine and check that the filter does not leak.
103
