Dynapac CC1000 - Dimensions, Side View

Technical specifications
4812160801_D.pdf 2018-12-17
Dimensions, side view
Dimensions mm inDimensions mm in
A Wheel base 1350 53.2A Wheel base 1350 53.2
D Diameter, drum 588 23.2D Diameter, drum 588 23.2
H Height, with ROPS 2300 90.6H Height, with ROPS 2300 90.6
h Height, without ROPS 1520 59.8h Height, without ROPS 1520 59.8
K
1
465 18.3K
1
465 18.3
L
1
2095 82.5L
1
2095 82.5
L
2
2040 80.3L
2
2040 80.3
S Thickness, drum amplitude,
Nominal
S Thickness, drum amplitude,
Nominal
CC800 14 0.55CC800 14 0.55
CC900 15 0.59CC900 15 0.59
CC1000 13 0.51CC1000 13 0.51
14
