Machine description
4812160801_D.pdf 2018-12-17
Fuses in engine compartment
Fig. Fuses, engine compartment
1. Heater plugs
2. Main fuse
1
2
The figure shows the position of the fuses.
The amperage and function of the fuses are shown
below. All fuses are flat pin fuses.
Fuses in engine compartmentFuses in engine compartment
F10 Main fuse (Type E - High) 30AF10 Main fuse (Type E - High) 30A
F20 Heater plugs 50AF20 Heater plugs 50A
Relays
Fig. Relays
1
2
3
4
1. K1 Starting1. K1 Starting
2. K5 Glow plug2. K5 Glow plug
3. K9 Direction indicators3. K9 Direction indicators
4. K10 Brake lights4. K10 Brake lights
34
