Machine description
4812160801_D.pdf2018-12-17
No Designation Symbol FunctionNo Designation Symbol Function
24. Warning lamp, oil
pressure
This lamp lights if the lubricating pressure in the
engine is too low. Stop the engine immediately and
locate the fault.
24. Warning lamp, oil
pressure
This lamp lights if the lubricating pressure in the
engine is too low. Stop the engine immediately and
locate the fault.
25. Warning lamp,
parking brake
The lamp lights when the parking brake is activated.25. Warning lamp,
parking brake
The lamp lights when the parking brake is activated.
26. Fuel level Shows the fuel level in the diesel tank.26. Fuel level Shows the fuel level in the diesel tank.
27. Warning lamp,
water temperature
The light comes on if the water temperature is too
high.
27. Warning lamp,
water temperature
The light comes on if the water temperature is too
high.
28. Warning lamp,
battery charging
If the lamp lights while the engine is running the
alternator is not charging. Stop the engine and
locate the fault.
28. Warning lamp,
battery charging
If the lamp lights while the engine is running the
alternator is not charging. Stop the engine and
locate the fault.
29. Warning lamp,
glow plug
The lamp must go out before the starter switch is
moved to position 3c for activation of the starter
motor.
29. Warning lamp,
glow plug
The lamp must go out before the starter switch is
moved to position 3c for activation of the starter
motor.
30. Hourmeter Shows the number of hours the engine has run.30. Hourmeter Shows the number of hours the engine has run.
31. Parking brake
On/Off, switch
To activate the brakes, press the top of the switch to
change the position of the lever.
To disengage the brakes, press down the red part at
the same time as the switch, and change the position
of the lever.
NOTE: When starting the machine, the parking brake
must be activated.
Always use the parking brake when the machine
is stationary on a sloping surface.
31. Parking brake
On/Off, switch
To activate the brakes, press the top of the switch to
change the position of the lever.
To disengage the brakes, press down the red part at
the same time as the switch, and change the position
of the lever.
NOTE: When starting the machine, the parking brake
must be activated.
Always use the parking brake when the machine
is stationary on a sloping surface.
Electrical system
Fuses
Fig. Fuse box
The figure shows the position of the fuses.
The table below gives fuse amperage and function. All
fuses are flat pin fuses.
Fuses in the fuseboxFuses in the fusebox
1.
ECU Instrument panel, Sprinkler 20A
5.
Hazard beacon 10A
1.
ECU Instrument panel, Sprinkler 20A
5.
Hazard beacon 10A
2.
Horn, Alternator, Fuel pump 10A
6.
Direction indicators, Power socket 12V 10A
2.
Horn, Alternator, Fuel pump 10A
6.
Direction indicators, Power socket 12V 10A
3.
Right direction indicators, Side
repeaters
5A
7.
Driving lights, Working lights main headlight
front
15A
3.
Right direction indicators, Side
repeaters
5A
7.
Driving lights, Working lights main headlight
front
15A
4.
Left direction indicators, Side repeaters 5A
8.
Driving lights, Position lights, Brake lights,
Working lights rear, Number sign lighting
15A
4.
Left direction indicators, Side repeaters 5A
8.
Driving lights, Position lights, Brake lights,
Working lights rear, Number sign lighting
15A
33
