Operation
4812160801_D.pdf2018-12-17
Interlock
The roller is equipped with Interlock.
Roller equipped with Sauer-Danfoss ECU:
The diesel engine with switch off after 4 seconds if the
operator gets off the seat when going
forwards/backwards.
If the control is in neutral when the operator stands up
a buzzer will go on until the parking brake button is
activated.
The engine does not stop if the parking brake is
activated.
The diesel engine will switch off immediately if for any
reason the forward/reverse lever is moved out of
neutral when the operator is not sitting down and the
parking brake button has not been activated.
Roller equipped with HY-TTC 71 ECU:
If the operator is leaving the seat with the diesel
engine running, travel lever in neutral position and
parking brake disengaged, the buzzer will set and the
diesel engine will shut down after four seconds.
During these four seconds the diesel engine shut
down can be rescinded either by engaging the parking
brake or to be seated.
If the operator is not seated and move the travel lever
out of neutral position, the buzzer will set and the
diesel engine will shut down instantly.
Sit down for all operations!Sit down for all operations!
37
