Operation
4812160801_D.pdf2018-12-17
Parking
Chocking the drums
Fig. Set-up
1. Chocks
1
Never leave the operator platform without
activating the parking brake (31).
Never leave the operator platform without
activating the parking brake (31).
Make sure that the roller is parked in a safe place
with respect to other road users. Chock the drums
if the roller is parked on sloping ground.
Make sure that the roller is parked in a safe place
with respect to other road users. Chock the drums
if the roller is parked on sloping ground.
Keep in mind that there is a risk of freezing during
the winter. Drain the water tanks and water lines.
Keep in mind that there is a risk of freezing during
the winter. Drain the water tanks and water lines.
Master switch - Optional
1
2
Fig. Battery compartment
1. Battery disconnector
(only PLUS version)
2. Power socket, 12V
3. Cable lug
3
The power to the roller should be disconnected at the
end of the working shift.
PLUS version
Put the battery disconnector (1) in the Off position and
remove the key.
CC version
Remove the red cable lug (3) from the plus terminal on
the battery.
This will prevent battery discharging and will also
make it difficult for unauthorized persons to start and
operate the machine. Lock also the engine cover.
45
