Technical specifications
4812161201_F.pdf 2018-04-17
Weights and volumes
WeightsWeights
Weight CECE, Standard
equipped roller
3750 kg 8,270 lbsWeight CECE, Standard
equipped roller
3750 kg 8,270 lbs
Fluid volumesFluid volumes
Fuel tank 50 liter 52.9 qts
Fuel tank 50 liter 52.9 qts
Emulsions tank 40 liter 42.2 qtsEmulsions tank 40 liter 42.2 qts
Water tank 200 liter 211.4 qtsWater tank 200 liter 211.4 qts
Working capacity
Compaction dataCompaction data
Static linear load 14,8 kg/cm 82.9 psi
Static linear load 14,8 kg/cm 82.9 psi
Amplitude 0,5 mm 0.019 inAmplitude 0,5 mm 0.019 in
Vibration frequency 52 Hz 3,120 vpmVibration frequency 52 Hz 3,120 vpm
Centrifugal force 33 kN 7,425 lbCentrifugal force 33 kN 7,425 lb
Note: The frequency is measured at high revs. The
amplitude is measured as the real value and not
the nominal.
PropulsionPropulsion
Speed range 0-10 km/h 0-6.2 mphSpeed range 0-10 km/h 0-6.2 mph
Climbing capacity (theoretical) 36 %Climbing capacity (theoretical) 36 %
General
EngineEngine
Manufacturer/Model Kubota V2203-M-E3BManufacturer/Model Kubota V2203-M-E3B
Power (SAE J1995) 33,3 kW 45 hpPower (SAE J1995) 33,3 kW 45 hp
Engine speed 2600 rpmEngine speed 2600 rpm
TiresTires
Tire dimensions 7.50-16Tire dimensions 7.50-16
Air pressure (kPa) 240 - 300 34.8 - 43.5 psiAir pressure (kPa) 240 - 300 34.8 - 43.5 psi
16
