Machine description
4812161201_F.pdf 2018-04-17
Locations - Control panel and controls
1 Starter switch1 Starter switch
2 Throttle control2 Throttle control
3 Emergency stop3 Emergency stop
4 Vibration On/Off4 Vibration On/Off
5 Handbook compartment5 Handbook compartment
6 Forward/reverse lever6 Forward/reverse lever
7 Seat switch7 Seat switch
8 Fuse box8 Fuse box
9 Instrument cover9 Instrument cover
Fig. Operator position
Fig. Operator's
station
1
3
8
4 6
5
9
7
31
2
30
