Operation
4812161201_F.pdf 2018-04-17
Switching off
1
2
31
22
9
Figure. Instrument panel
1. Starter switch
2. Throttle control
9. Instrument cover
22. Panel for warning lamps
31. Parking brake
Turn the throttle control (2) back to idling. Allow the
engine to idle for a few minutes to cool.
Activate the parking brake (31).
Check instruments and warning lamps to see if any
faults are indicated. Switch off all lights and other
electrical functions.
Turn the starter switch (1) to the left to the switched off
position. At the end of the shift, fold over the
instrument cover (9) and lock.
Parking
Chocking the wheels/drum
Fig. Drum part
1. Chocks
1
Never disembark from the machine when the is
engine running, unless the parking brake is
activated.
Never disembark from the machine when the is
engine running, unless the parking brake is
activated.
Make sure that the roller is parked in a safe place
with respect to other road users. Chock the drum
and rubber wheels if the roller is parked on sloping
ground.
Make sure that the roller is parked in a safe place
with respect to other road users. Chock the drum
and rubber wheels if the roller is parked on sloping
ground.
Remember that there is a risk of freezing during
the winter. Empty the water tank. Fill antifreeze in
the engine's cooling system. See also
maintenance instructions.
Remember that there is a risk of freezing during
the winter. Empty the water tank. Fill antifreeze in
the engine's cooling system. See also
maintenance instructions.
44
