Maintenance, 10h
4812161201_F.pdf2018-04-17
1
2
3
Fig. Pump system
1. Water filter
2. Stop cock
3. Water pump
When cleaning the coarse filter (1), open the cock (2)
and loosen the filter housing.
Clean the filter and filter housing. Check that the
rubber gasket in the filter housing is intact.
After inspecting and carrying out any necessary
cleaning, start the system and check that it works.
A drain cock is placed on the left side of the pump
system area. This can be used to drain the tank and
the pump system.
Pump system / Tire
Check - Cleaning
1
2
Fig. Left footstep
1. Filter housing
2. Cock
When cleaning, close the stop cock (2) and undo the
filter house (1). Clean the filter and filter housing.
Listen to or put your hand on the water pump to check
that it is working.
79
