Dynapac CC1300C User Manual

Machine description
4812161201_F.pdf2018-04-17
No Designation Symbol FunctionNo Designation Symbol Function
29. Warning lamp, glow plug The lamp must go out before the starter switch is moved to
position 3c for activation of the starter motor.
29. Warning lamp, glow plug The lamp must go out before the starter switch is moved to
position 3c for activation of the starter motor.
30. Hourmeter Shows the number of hours the engine has run.30. Hourmeter Shows the number of hours the engine has run.
31. Parking brake On/Off,
switch
To activate the brakes, press the top of the switch to change the
position of the lever.
To disengage the brakes, press down the red part at the same
time as the switch, and change the position of the lever.
NOTE: When starting the machine, the parking brake must be
activated.
Always use the parking brake when the machine is stationary
on a sloping surface.
31. Parking brake On/Off,
switch
To activate the brakes, press the top of the switch to change the
position of the lever.
To disengage the brakes, press down the red part at the same
time as the switch, and change the position of the lever.
NOTE: When starting the machine, the parking brake must be
activated.
Always use the parking brake when the machine is stationary
on a sloping surface.
Electrical system
Fuses
Fig. Fuse boxes
1. Upper
2. Lower
1
2
The figure shows the position of the fuses.
The table below gives fuse amperage and function. All
fuses are flat pin fuses.
Fuse box, Upper Fuse box, LowerFuse box, Upper Fuse box, Lower
1. ECU, Interlock, Instrument panel,
Sprinkler front, Vibration
10A 1. Reserve
1. ECU, Interlock, Instrument panel,
Sprinkler front, Vibration
10A 1. Reserve
2. Alternator, Horn, Fuel pump 10A 2. Flow divider, Sprinkler combi wheel 10A2. Alternator, Horn, Fuel pump 10A 2. Flow divider, Sprinkler combi wheel 10A
3. Indicators left 5A3. Indicators left 5A
4. Indicators right 5A4. Indicators right 5A
5. Hazard beacon 10A5. Hazard beacon 10A
6. Indicator relay, Power socket 12V 10A6. Indicator relay, Power socket 12V 10A
7. Position lights, Working lights front 15A7. Position lights, Working lights front 15A
8. Traffic lights, Working lights rear 15A8. Traffic lights, Working lights rear 15A
