Dynapac CC1300C User Manual

Machine description
4812161201_F.pdf 2018-04-17
No Designation Symbol FunctionNo Designation Symbol Function
15. Working lights, switch When depressed, the working lights are on15. Working lights, switch When depressed, the working lights are on
16. Hazard warning lights,
switch (Optional)
Where depressed, the hazard warning lights are on16. Hazard warning lights,
switch (Optional)
Where depressed, the hazard warning lights are on
17. Hazard beacon, switch Where depressed, the hazard beacon is on17. Hazard beacon, switch Where depressed, the hazard beacon is on
18. Direction indicators, switch
(Optional)
When depressed to the left, the left direction indicators are on etc.
In the middle position the function is shut off.
18. Direction indicators, switch
(Optional)
When depressed to the left, the left direction indicators are on etc.
In the middle position the function is shut off.
19. Horn, switch Press to sound the horn.19. Horn, switch Press to sound the horn.
20. Vibration MAN/AUTO,
switch
In the upper position, the vibration is switched on/off with the
switch on the forward/reverse lever. The function is activated with
the switch.
In the intermediate position the vibration system is completely
switched off.
In the lower position the vibration is switched on or off
automatically via the forward/reverse lever.
20. Vibration MAN/AUTO,
switch
In the upper position, the vibration is switched on/off with the
switch on the forward/reverse lever. The function is activated with
the switch.
In the intermediate position the vibration system is completely
switched off.
In the lower position the vibration is switched on or off
automatically via the forward/reverse lever.
21. Sprinkler system tires,
switch
Regulates water flow to the tires.
Upper position = Intermittent operation
Lower position = Continuous operation
21. Sprinkler system tires,
switch
Regulates water flow to the tires.
Upper position = Intermittent operation
Lower position = Continuous operation
22. Control panel22. Control panel
23. Warning lamp, low fuel
level
The lamp comes on when the fuel level in the tank is low.23. Warning lamp, low fuel
level
The lamp comes on when the fuel level in the tank is low.
24. Warning lamp, oil pressure This lamp lights if the lubricating pressure in the engine is too low.
Stop the engine immediately and locate the fault.
24. Warning lamp, oil pressure This lamp lights if the lubricating pressure in the engine is too low.
Stop the engine immediately and locate the fault.
25. Warning lamp, parking
brake
The lamp lights when the parking brake is activated.25. Warning lamp, parking
brake
The lamp lights when the parking brake is activated.
26. Fuel level Shows the fuel level in the diesel tank.26. Fuel level Shows the fuel level in the diesel tank.
27. Warning lamp, water
temperature
The light comes on if the water temperature is too high.27. Warning lamp, water
temperature
The light comes on if the water temperature is too high.
28. Warning lamp, battery
charging
If the lamp lights while the engine is running the alternator is not
charging. Stop the engine and locate the fault.
28. Warning lamp, battery
charging
If the lamp lights while the engine is running the alternator is not
charging. Stop the engine and locate the fault.
32
