Common Services
Service Code
Implemented for
Service Name
Class Level Instance Level
05
HEX
No Yes Reset
0E
HEX
Yes Yes Get_Attribute_Single
10
HEX
No Yes Set_Attribute_Single
Message Router Object (02
HEX
– 1 Instance)
***No supported services or attributes***
Assembly Object (04HEX – 2 Instances)
Class Attributes (Instance 0)
Attribute ID Name Data Type Data Value Access Rule
1 Revision UINT 2 Get
2 Max Instance UINT 101 Get
Input Instance Attributes (Instance 100)
Attribute ID Name Data Type Default Data Value Access Rule
3 Input Data USINT[56] 0 Get
Input Instance 100 – 100 Bytes (Single Precision Floating Point)
Bytes Description
0 - 3 Signal Strength
4 - 7 Flow Rate
8 - 11 Net Totalizer
12 - 15 Positive Totalizer
16 - 19 Negative Totalizer
20 - 23 Temp1 degC
24 - 27 Temp2 degC
28 - 31 Diff Temp(1-2) degC
32 - 35 Diff Temp(2-1) degC
36 - 39 Abs Diff Temp degC
40 - 43 Temp1 degF
44 - 47 Temp2 degF
48 - 51 Diff Temp(1-2) degF
52 - 55 Diff Temp(2-1) degF
56 - 59 Abs Diff Temp degF
60 - 63 Flow Rate GPM
64 - 67 Flow Rate LPM
68 - 71 Flow Rate CFH
72 - 75 Flow Rate CMH
76 - 79 Flow Rate FPS
80 - 83 Flow Rate MPS
84 - 87 Flow Unit Code
88 - 91 Total Unit Code
92 - 95 Total Exponent Unit Code
96 - 99 Time Unit Code
Communications Protocols
Page 68 May 2016TTM-UM-00136-EN-06
