Input Instance 101 – 200 Bytes (Double Precision Floating Point)
Bytes Description
0 - 7 Signal Strength
8 - 15 Flow Rate
16 - 23 Net Totalizer
24 - 31 Positive Totalizer
32 - 39 Negative Totalizer
40 - 47 Temp1 degC
48 - 55 Temp2 degC
56 - 63 Di Temp(1-2) degC
64 - 71 Di Temp(2-1) degC
72 - 79 Abs Di Temp degC
80 - 87 Temp1 degF
88 - 95 Temp2 degF
96 - 103 Di Temp(1-2) degF
104 - 111 Di Temp(2-1) degF
112 - 119 Abs Di Temp degF
120 - 127 Flow Rate GPM
128 - 135 Flow Rate LPM
136 - 143 Flow Rate CFH
144 - 151 Flow Rate CMH
152 - 159 Flow Rate FPS
160 - 167 Flow Rate MPS
168 - 175 Flow Unit Code
176 - 183 Total Unit Code
184 - 191 Total Exponent Unit Code
192 - 199 Time Unit Code
Input Instance Common Services
Service Code
Implemented for
Service Name
Class Level Instance Level
0E
HEX
Yes Yes Get_Attribute_Single
Connection Manager Object (06
HEX
)
***No supported services or attributes***
