Eaton 93PR 15-80 kW UPS

Installation and Operation Manual

3. Turn on the external bypass distribution switch;

4. Observe the logic power supply indicated on the UPS control panel;

5. Make sure that there is no alarm;

6. Click “Control” on the menu, and enter the password to access the control page;

7. Select “System” on the control interface;

8. Click the “Start” button on the system interface, and press “OK” to start the system;

9. When the rectier and inverter are started and the inverter voltage reaches the set value,

“Online” status is displayed and the online indicator lamp (green) is lit;

10. At this point, the UPS is running in online mode, and all UPS status indicator lamps in the

system indicate online mode.

6.4.2. UPS shutdown

Shutdown is allowed only when a single UPS is redundant in the system. Namely, shutdown is

not allowed if the shutdown of a single UPS will cause system overload.

Shut down a single UPS:

1. Click the “Control” button on the main page to switch to the “System Control” page;

2. Press the “UPS Control” button on the “System Control” page;

3. Click “Shutdown” on the “UPS Control” page.

Start or shut down the battery charger

Please perform the following steps to start or shut down the battery charger:

1. Click the “Control” button on the main page to switch to the “System Control” page;

2. Press the “UPS Control” button on the “System Control” page;

3. Press “Charger On” or “Charger Off” on the “UPS Control” page.
