Eaton DS7 User Manual

0 About this Manual
0.3 Sources
6 DS7 Soft starter 09/16 MN03901001Z-EN www.eaton.com
0.3 Sources
[1] Profile Drive Technology, PROFIdrive Technical Specification for
PROFIBUS and PROFINET, Version 4.1, May 2006; Order No: 3.172
0.4 Target group
The content of the manual is written for engineers and electricians. A
specialist knowledge of electrical engineering is needed for commissioning.
The chapter “SmartWire-DT” is intended for automation technicians and
engineers. Detailed knowledge of the field bus systems used is presumed.
In addition you should be familiar with the handling of the SmartWire-DT
system.
￫
More information on the devices described here can be found on
the Internet under:
http://www.eaton.eu/Europe/Electrical/ProductsServices/
AutomationControl/SwitchingProtectingDrivingMotors/SoftStarters/DS7/
as well as
http://www.eaton.de/EN/EatonDE/ProdukteundLoesungen/Electrical/
Kundensupport/DownloadCenter/index.htm
￫ Customer support ￫ Download Center – Documentation
In the Quick Search box, enter the document name
(MN03901001).

Eaton DS7 Specifications

General

Product type	-
Certification	IEC/EN 60947-4-2, UL 508, CSA22.2-14
Product color	Gray
Protection class	I
International Protection (IP) code	IP20
Input voltage	200 - 480 V
DC input voltage	24 V
AC input frequency (fridge)	50/60 Hz
Sustainability compliance	Yes
Sustainability certificates	CE
Operating temperature (T-T)	-40 - 40 °C

Weight and Dimensions

Weight	1800 g
