Eaton DS7 User Manual

9 Appendix
9.3 Specific technical data
218 DS7 Soft starter 09/16 MN03901001Z-EN www.eaton.com
9.3.3 Heat dissipation P
V
The heat dissipation P
V
of the soft starter depends on the operating state of
the connected motor.
The values in Table 46 refer to the rated operation of the motor sizes
(motor rating, 4 pole three-phase asynchronous motor) at an ambient air
temperature of +40 °C.
Table 46: Heat dissipation
The start produces currents above the rated operational current.
All enclosure types in which the Soft starter is to be installed must have the
required power loss capacity. Depending on the ramp time set and the
current limitation, this current can be present for several seconds.
The resulting heat dissipation must in this case be allowed for in the housing
design.
Part no. DC versions AC versions
Rated
operational
current
Heat dissipation in
standby
Heat dissipation at
rated load cycle
Heat dissipation in
standby
Heat dissipation at
rated load cycle
A W W W W
DS7-34xSX004N0-… 4 0.7 5 1.5 5
DS7-34xSX007N0-…
7 0.7 5 1.5 6
DS7-34xSX009N0-…
9 0.7 6 1.5 7
DS7-34xSX012N0-…
12 0.7 7 1.5 8
DS7-34xSX016N0-…
16 0.7 7 1.5 7
DS7-34xSX024N0-…
24 0.7 9 1.5 10
DS7-34xSX032N0-…
32 0.7 12 1.5 13
DS7-34xSX041N0-…
41 0.7 7 1.5 8
DS7-34xSX055N0-…
55 0.7 9 1.5 10
DS7-34xSX070N0-…
70 0.7 11 1.5 12
DS7-34xSX081N0-…
81 0.7 13 1.5 14
DS7-34xSX100N0-…
100 0.7 16 1.5 17
DS7-34xSX135N0-…
135 0.7 24 1.5 25
DS7-34xSX160N0-…
160 0.7 30 1.5 31
DS7-34xSX200N0-…
200 0.7 42 1.5 43
