0 About this Manual
0.6 Abbreviations
8 DS7 Soft starter 09/16 MN03901001Z-EN www.eaton.com
0.6 Abbreviations
The following abbreviations are used in this manual:
0.7 Mains supply voltages
The rated operating voltages stated in the following table are based on the
standard values.
In ring networks (as found in Europe) the rated operating voltage at the
transfer point of the power supply companies is the same as the value in the
consumer networks (e.g. 230 V or 400 V).
In star networks (as found in North America), the rated operating voltage at
the transfer point of the utility companies is higher than in the consumer
network.
Example: 120 V → 115 V, 240 V → 230 V, 480 V → 460 V.
The wide tolerance range of the DS7 soft starters allows for voltage drops of
10% and a voltage drop of additional 4 %, as well as an excess voltage of
10 % that are permissible in consumer supply networks.
The rated mains voltage operational data is always based on mains
frequencies of 50/60 Hz (50 Hz - 5 % – 60 Hz +5 %).
Abbreviation Meaning
BG Construction size
DS
Default settings
DS7-SWD
DS7 soft starter with SmartWire-DT
(abbreviated designation for devices with part no. DS7-34D…)
EMC
Electromagnetic compatibility
GND
Ground (0-V-potential)
LED
Light Emitting Diode (LED)
PDS
Power Drive System (magnet system)
RCD
Residual Current Device (residual current circuit-breaker)
SmartWire-DT
SmartWire-DT
TOR
Top of Ramp
t-Start
Ramp time for start voltage
t-Stop
Ramp time for voltage reduction
U-Start
Start voltage
UL
Underwriters Laboratories
U
LN
Mains voltage
+U
s
/-U
s
Control voltage

Eaton DS7 Specifications

General

Product type	-
Certification	IEC/EN 60947-4-2, UL 508, CSA22.2-14
Product color	Gray
Protection class	I
International Protection (IP) code	IP20
Input voltage	200 - 480 V
DC input voltage	24 V
AC input frequency (fridge)	50/60 Hz
Sustainability compliance	Yes
Sustainability certificates	CE
Operating temperature (T-T)	-40 - 40 °C

Weight and Dimensions

Weight	1800 g
