7.3 Error message examples
Example 1: Perform code generation for the process image [EA assignment].
Signal List
The same EA address is entered in rows 115 and 117
.
Example 2: Perform code generation for the setpoints
Signal List
In row 133,
the setpoint 300 is above the set maximum of 45!
Example 3: Carry out code generation for the process image [IO assignment].
Signal List
In row 141,
"MX5.0.2 h" instead of "MX5.0.2" was entered in the E/A area!
Note
Simply double click on one of the error messages in the status line to display the error highlighted in
colour in the Signal List.
