9.3.5 Power supply
DANGER
Warning about dangerous electrical voltage! Danger to life - Danger of electric shock! BEFORE
connection and disconnection, it mustbecheckedthatthe230VACpowersupplycableis
disconnected from the power supply! The controller is only permitted to be connected to the
intended operating voltage of 230 V AC!
ATTENTION
A circuit breaker must be used to protect the mains cable and must not interrupt the earth conductor
(PE). For details, see chapter Assignment of the 230 V AC power supply.
The controller can be put into operation after completion of the mechanical and electrical installation.
After connecting to the power supply, the green LED (POWER) lights briefly after switching on, see
chapter Status LEDs.
Note: As the controller itself does not have a switch for switching on or off, it must be disconnected
from the power supply for e.g. a Restart for approx. 2 seconds (switch on/off the circuit breaker).
