14 Technical Data GLT x010 / SIOX
14.1 Electrical Data GLT x010 / SIOX
Basic module SIOX extension module
Operating voltage 230 V AC, 200 ... 265 V AC, 50/60 Hz 24 V DC / 9 V DC
supply via basic module
Rated power 24 VA 3.1 W
Leakage current over PE
(protective earth)
max 1 mA
Digital inputs 23 x optionally 230 V AC or 24 V AC/DC, floating 12 x optionally 230 V AC or 24 V AC/DC,
floating
Relay outputs 10 x 230 V AC, max. 6 A / min. 10 mA (6 NO
contacts, 4 changeover contacts), floating
8 x 230 V AC / max. 6 A / min. 10 mA
(4 x NO contacts, 4 x changeover contacts)
floating
Manual control switch The pack controller as well as the extension modules have manual control switches
so that the regulation can be manually overridden in emergency operation, see chapter Manual /
Automatic operating modes changeover.
Analogue inputs 1) 13 x Pt1000 2-wire temperature sensor
2 x Pt1000 4-wire temperature sensor
6 x 4..20 mA (resistance 400 ohm)
1 x 0..10 V
-
Analogue outputs 1) 4 x 0..10 V / 4..20 mA
0..10V(loadmin.1kΩ)/4..20mA(resistancemax.
800 ohm)
-
1) Supply cables to analogue inputs / outputs must be shielded.
DANGER
Overvoltage category III / contamination degree 2:
All connections of the device provided for operation with 230 V AC supply voltage must be wired with
the same phase conductor. 400 V AC between neighbouring connection terminals is not permitted!
Overvoltage category II / contamination degree 2 or
overvoltage category II / contamination degree 1:
Different phase conductors may be used. 400 V AC between neighbouring connection terminals is
permitted!
