Coding switches 6..7
Coding switches 6 and 7 determine the operating mode of the controller:
Coding switches 6..7 Switch position
for 6 and 7
Function
ON Normal operation (factory setting)
OFF Firmware update mode
ATTENTION
The coding switches 6 and 7 may only be set to OFF for the purpose of the firmware update! In this
state, the controller waits for the firmware update via a connected service PC. It is strictly required for
the normal operation of the system that the firmware update mode is deactivated - DIP switch S1
coding switches 6 and 7 must be in the ON position!
After changing the switch positions of the coding switches 6 and 7, the controller must be
disconnected from the power supply for a short time so that the desired settings will be adopted!
