Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
■ Checking the wiring from Tube Stand’s Handle bar Connector TS-HD-IO-2 Connector to Generator
MiO Board.
PIN NO
Upper Side, Generator
P805 (Rotor)
P976
1
SM
AC21V
2
NC
AC 0V (COM)
3
SS
??
4
NC
AC21V
5
SC
AC 0V (COM)
6
SM
NC
7
NC
NC
8
SS
NC
9
NC
NC
10
SC
Emergency SW
11
Emergency SW
12
NC
13
Tube Temp. SW
14
Tube Temp. SW
15
Door SW
16
Door SW
17
GND
18
GND
