Ecoray HF-525Plus - Appendix 2 Anatomical Programming Radiographic

225
Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
Appendix 2 Anatomical Programming Radiographic
Icon
Function
Small body size.
X-Ray Exposure position
kV
mA
mSec
mAs
Skull
AP
66
320
20
6.4
LAT
80
320
55
17.6
OBL
75
320
40
12.8
Mandible
AP
64
320
35
11.2
LAT
74
320
55
17.6
OBL
70
320
40
12.8
Nasal
AP
68
320
35
11.2
LAT
74
320
50
16
OBL
68
320
40
12.8
Chest
AP
70
320
60
19.2
LAT
70
320
50
16
OBL
66
320
40
12.8
Shoulder
AP
64
320
40
12.8
LAT
64
320
35
11.2
OBL
64
320
25
8
Sternum View
AP
60
320
30
9.6
LAT
50
320
4
1.28
OBL
48
320
7
2.24
C-Spine
AP
66
320
50
16
LAT
66
320
40
12.8
OBL
62
320
35
11.2
L-Spine
AP
72
320
80
25.6
LAT
80
320
120
38.4
OBL
72
320
90
28.8
T-Spine
AP
67
320
50
16
LAT
78
320
60
19.2
OBL
70
320
50
16
Abdomen
AP
70
320
50
16
LAT
76
320
70
22.4
OBL
70
320
55
17.6
