Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
12.1 Introduction
HF-525 Plus monitors the Generator fault status in real-time electrical circuit and sends the fault
information to the Console when the X-ray system fails display the fault information on the display
window. The fault status is organized by Error Code and provides a solution to repair X-ray system
user or service person in order to easily solve the faulty part of X-ray system.
12.2 Repair Tools
The basic tools and measuring equipment required for troubleshooting are listed below. Additional
tools and measuring equipment should be prepared according to the fault condition.
● Basic and common measuring equipment and installation tools used by engineers (For example, a
Multi meter, a driver, a ripper, a long rose, a range set, a lead, a soldering iron, a hexagon range set,
etc.)
● Tools to clean parts
● Tube voltage meter (kV meter).
● Tube current meter (mA meter).
● Radiation dose meter (Radiation Dose meter).
● Service manual 1 booklet
12.3 Error type and display
12.3.1. Error type 1: Displayed E r r C r F P at kVp, mA, Time section
12.3.2 Error type 2: Displayed E r r C r F at kVp, mA, Time section
12.3.3 Error type 3: Displayed E r r C r P at kVp, mA, Time section
12.3.4 Error type 4: Displayed E r r C r at kVp, mA, Time section
12.3.5 Error type 5: Displayed E r r C FP at kVp, mA, Time section
Tube
Stator
Circuit
error
To be checked
(Any one of 4 is possibly faulty)
Tube
Stator
Circuit
error
Tube
Stator
Circuit
error
To be checked
(Any one of 4 is possibly faulty)
Tube
Stator
Circuit
error
To Next Page
