Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
9 Specification
9.1 Operator's Console
Type
Microprocessor control & Digital display
Indication meter
kV, mA, mAs or msec
mA setting
10mA to 500mA (±5%)
kV setting
40kV to 125KV (±5%)
Time setting
10msec ~ 6.3sec
Anatomical mode (APR)
288 preset anatomical programs
Console Mount
Desk top or Wall-mount bracket style
Dimension
Approx. 420 x 330 x 110mm
Weight
Approx. 1kg
9.2 Generator
Model
F40
F32
Power consumption
40kW
32kW
Power supply
230V, 50/60Hz, Single phase
kV range
40~125KV
mA range (Max)
500
400
Time range
10msec ~ 6.3sec
Maximum output
(at 100msec)
500mA/80kV,
320mA/125kV
400mA/80kV,
250mA/125kV
Automatic Line
Compensation
±10%
Interval time After
Exposure
1minute at 80KV, 500mA, 100msec.
Reproducibility
Coefficient of Variation: kV < 0.005, Time < 0.005, mAs < 0.01
Accuracy
kV<±(1%+1kV), mA<±(3%+1mA), Time<±(1%+0.5ms), mAs<±(3%+0.1mAs)
Self-diagnosing
function
Over load, Error code display
High Voltage
Transformer type
Full Bridge circuit rectification type
Dimension
Approx. 600 x 570 x 470mm
Weight
Approx. 130kg
9.3 X-ray Tube
Type
Rotating anode x-ray tube assembly
