Ecoray HF-525Plus - Wall Bucky Stand; Ceiling Tube Support (Optional)

188
Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
Grid specification
Ratio: 10:1, 103lines/inch
X-ray IMAGE RECEPTOR
Film cassette OR DR Detector
Cassette loading
From front side
Tabletop locking
Electromagnetic lock by optical sensor
Dimension
Approx. 2,200 x 700 x 700mm
Weight
140Kg
Power supply
24V AC
SID
Under 80mm (Distance between detector and table top)
9.9 Wall Bucky Stand
Compatible cassette sizes inch
8"x 10"∼17"x17"
Grid specification
Ratio: 10:1, 103lines/inch
X-ray IMAGE RECEPTOR
Film cassette OR DR Detector
Cassette loading
From right or left side (decided at installation)
Bucky vertical lock
Electromagnetic lock by push button
Vertical Travel
Approx. 1,500mm (400mm ~ 1,900mm above floor)
Inherent Filtration
0.8mm Al
Dimension
Approx. 2100mm (H)
Weight
Approx. 155Kg
Power supply
24V AC
SID
Under 50mm
(Distance between Director and Wall Bucky exterior)
9.10 Ceiling Tube Support (Optional)
Type
Ceiling-mounted overhead suspension tube support system
Rail size
Up rail: 630mm x 3,000mm, Bellow rail: 3,500mm x 1,700mm
Vertical travel
Approx. 1,200mm
Transverse travel
Approx. 2,100mm - Different by room & rail size
Longitudinal travel
Approx. 3,500mm - Different by room & rail size
Rotation range of tube arm
±180°
Rotation range of column
±180°
Rotation range of tube handle
±90°
Power supply
24V AC
Tube positioning (Roll and Yaw)
Clutch brake
