Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
Added Filtration
0.8mm Al
Maximum X-ray Field size
Below 5cm x 5cm at SID 100cm
Minimum X-ray Field size
Below 35cm x 35cm at SID 65cm
Light projection
More than 160lux at SID 100Cm
Lamp timer
Approx. 30sec (Push button type)
Dimension
Approx. 185 x 220 x 180mm
Weight
Approx. 5Kg
9.7 Table Bucky (4-Way)
Type
Wide 4 way floating table top
Compatible cassette sizes inch
8"x 10"∼17"x17"
Longitudinal table top movement
Approx. ±150mm
Transverse table top movement
Approx. ±450mm
Movement of Bucky Device
Approx. 400mm
Maximum load of tabletop
Approx. 200kg
Inherent Filtration
0.8mm Al
Grid specification
Ratio: 10:1, 103lines/inch
X-ray IMAGE RECEPTOR
Film cassette OR DR Detector
Cassette loading
From front side
Tabletop locking
Electromagnetic lock by optical sensor
Dimension
Approx. 2,200 x 700 x 700mm
Weight
140Kg
Power supply
24V AC
SID
Under 80mm (Distance between detector and table top)
9.8 Table Bucky (6-Way, Optional)
Type
Wide 6 way floating table top
Compatible cassette sizes inch
8"x 10"∼17"x17"
UP & Down movement
Approx. 500~840mm이내
Longitudinal table top movement
Approx. ±150mm
Transverse table top movement
Approx. ±450mm
Movement of Bucky Device
Approx. 400mm
Maximum load of tabletop
Approx. 200kg
Inherent Filtration
0.8mm Al
