HF-525Plus Installation, Operation and Service Manual
■ Check the supplied voltage to the generator.
■ Check the supplied voltage to the main board.
■ Check the internal parts of the generator and check for noise, heat, and smell.
■ Check the assembled parts of the generator.
■ Check the condition of wiring and ground wire fixed to the generator.
■ Check the tightness of the cable wired to the generator.
■ Clean the inside of the generator with a dry cloth, a brush, or an air compressor.
10.6.6 X-Ray Tube Check
■ Check the X-ray Tube by Service Engineer.
■ Make sure there are no water marks around the X-ray tube.
■ Check wiring condition and ground wire fixing condition on X-Ray Tube.
■ Check the X-Ray Tube for signs of oil leakage.
■ If any trace of oil is found on the X-ray tube, check the tube housing for cracks.
■ If any signs of oil leakage are found on the X-ray tube, clean it with a dry cloth.
■ Check the tightness of the bushing and receptacle of the high-voltage cable.
■ Remove the high-voltage cable and check the high-voltage cable bushing. If the bushing is bad,
wipe the bushing with a dry cloth and apply silicone oil to the receptacle.
■ Check operation and noise level of Tube Anode Rotor.
10.7 Main parts list
Main parts for Service are as below. For other parts please contact our customer service team.
After ordering
Factory
shipment date
Filament & IGBT Drive Board
