Ecoray HF-525Plus - Tube Stand; High Voltage Cable; Collimator

186
Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
Model
E7239X
Nominal Tube Voltage
40 to 125kVp Max. (Radiographic)
Anode heat storage
140,000HU
Nominal Focal Spot Value
Small: 1.0mm, Large: 2.0mm
Construction
Rhenium-Tungsten faced Molybdenum
Target angle
16°
Permanent filtration
0.9mmAl/75KV IEC 60522/2003
Weight
Approx. 16Kg
*For additional information, see the IFU of the X-ray Tube.
9.4 Tube Stand
Type
Floor standing type or Floor to Ceiling mounted type
Transverse travel
Approx. 2000mm
Vertical travel
Approx. 1,500mm (400~1900mm above floor)
Lateral travel tube arm
Approx. 260mm
Rotation range of vertical column
±180°
Rotation range of horizontal x-ray
beam
±180°
Floor rail size
Approx. 2,700mm long
Power supply
24V AC
Lock
Electro-magnetic brake system
Weight
Approx. 157kg (Except floor rail)
9.5 High Voltage cable
Length
6 M - Adjustable
Maximum permit voltage
150kVp
9.6 Collimator
Application
Adjustable with manual control knobs, exclusive use for
radiography
Power supply
24V AC
Maximum voltage
150kVp
Lamp
LED lamp 24V AC 150W
Inherent Filtration
1.5mm Al
