Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
5. Installation of HF-525Plus
5.1 Conditions for installation
Use environment
Ambient environment: 10℃ to 35℃
Relative humidity : 10% to 70% (no dew condition)
Atmospheric pressure: 800hPa to 1060hPa
Storage environment (without a package for transport and storage)
Ambient environment: -10℃ to 60℃
Relative humidity :10% to 90% (no dew condition)
Atmospheric pressure: 800hPa to 1060hPa
Transportation and Storage environment
Ambient temperature: -10℃ to 40℃
(The upper bound of the temperature is allowed up to 50℃ only for the period of less than one month.)
Relative humidity: 10% to 60%
Atmospheric pressure: 700hPa to 1060hPa
Power Supply
AC power System: Single phase AC
Frequency: 50/60Hz
Standard voltages: 230V.
Voltage variation range:±10% of standard voltages
Supply capacity: 60kVA(Change)
Supply Impedance: 100, 110, 120 V: 1.0Ω or less
200, 220, 230, 240 V: 4.0Ω or less
Earth terminal: Earth resistance of 100Ω or less
