Ecoray HF-525Plus - Tube Stand

15
Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
4.4 Tube stand
NO
Function
Function Description
1
Floor rail
Stand can move from left to right (right to left) – longitudinal way
2
Stand
Holding a tube and traveling Up/Down vertical way
3
X-Ray Tube
Where the X-ray does comes out
4
LCD Display
Displaying X-ray tube rotation angle and X-ray parameters.
5
Collimator
Determine X-ray exposure area.
