Ecoray HF-525Plus - Ceiling Tube Support (Option)

20
Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
4.9 Ceiling Tube Support (Option)
NO
Function
Function Description
1
X-axis Rail
Moving Rail Can Move Forward and Backward for Wagon
2
Wagon
Moving Column Upward and Downward and attach X-ray Tube
3
Column
This Column Moving X-ray Tube Device to Upward and to Downward
4
Handle bar
Electrical Magnetic Function, and Display Tube’s Rotator Angle, and
Display X-Ray Exposure Condition Changing
5
X-ray tube
X-ray Generation Tube
