4.6 Collimator
■ Function of Collimator
√ X-ray irradiation angle is adjusted by manual.
√ Function and description of Collimator is as below.
NO
Function
Function Description
1
X-ray EXP circle
Connecting to X-ray tube Window through a bracket
2
Knob (x axis)
Changing shutter position for x direction
3
Knob (y axis)
Changing shutter position for y direction
4
Lamp button
ON/OFF button for Lamp
