Ecoray HF-525Plus - Wall Bucky Stand

19
Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
4.8 Wall Bucky stand
NO
Function
Function Description
1
Bucky device
Device can move Up/Down with built-in Detector
2
Base plate
Stand Bucky can be fixed with this plate into the floor.
3
Duct port
Required cables come into the duct port.
4
Stand
Holding a tube and traveling Up/Down vertical way
