Ecoray HF-525Plus - Page 226

226
Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
Pelvis
AP
72
320
70
22.4
LAT
76
320
100
32
OBL
70
320
85
27.2
Hip Bone
AP
66
320
20
6.4
LAT
80
320
55
17.6
OBL
75
320
40
12.8
X-Ray Exposure position
kV
mA
mSec
mAs
Hand
AP
41
320
3
0.96
LAT
42
320
3
0.96
OBL
40
320
3
0.96
Elbow
AP
46
320
7
2.24
LAT
49
320
8
2.56
OBL
44
320
7
2.24
Forearm
AP
47
320
7
2.24
LAT
49
320
7
2.24
OBL
45
320
7
2.24
Foot
AP
46
320
10
3.2
LAT
51
320
10
3.2
OBL
46
320
10
3.2
Ankle
AP
52
320
11
3.52
LAT
55
320
11
3.52
OBL
52
320
11
3.52
Tibia
AP
54
320
17
5.44
LAT
57
320
17
5.44
OBL
53
320
17
5.44
Femur
AP
47
320
7
2.24
LAT
49
320
8
2.56
OBL
45
320
7
2.24
Knee
AP
55
320
17
5.44
LAT
59
320
17
5.44
OBL
54
320
17
5.44
Aux1
AP
72
320
35
11.2
LAT
80
320
70
22.4
OBL
72
320
55
17.6
Aux2
AP
72
320
35
11.2
LAT
80
320
70
22.4
OBL
72
320
55
17.6
