Technical Publication Document NO: SYSTEM-007-ENG (Ver.1.1)
HF-525Plus Installation, Operation and Service Manual
5.12.3 Consist of Main Part
■ Table
√ Bucky device restrains scattered X-ray.
√ Foot switch controls upper table which is fixed with electromagnet.
√ Fixture plate settles the product on the floor after the installation.
√ Patient lays down on the upper table which made with easy-radioactivity-penetrate material.
■ Bucky device
√ Cassette Tray locates cassette
√ Cassette holder is a fixture that does not move the cassette.
√ Grid is a lattice to get rid of scattered X-ray.
√ Oscillator moves grid right and left.
√ Ion Chamber controls exposure time automatically.
5.12.4 Unpacking
● Product is packed as one package to make easy its transportation and installation.
● Check any damage of the product after the unpacking.
● If any damage is found, stop the installation, user should inform about the damage to the forwarder
and the representative
● User should confirm every device is same as it ordered, do not dump any package, box, document
and other contents until completion of confirmation.
CAUTION ▶
At least 4 people work together to move tube stand for installation.
