T-Spine
AP
70
320
55
17.6
LAT
78
320
60
19.2
OBL
72
320
55
17.6
Abdomen
AP
72
320
55
17.6
LAT
76
320
70
22.4
OBL
72
320
60
19.2
Pelvis
AP
76
320
70
22.4
LAT
76
320
100
32
OBL
72
320
100
32
Hip Bone
AP
70
320
30
9.6
LAT
80
320
55
17.6
OBL
70
320
50
16
X-Ray Exposure position
kV
mA
mSec
mAs
Hand
AP
42
320
3
0.96
LAT
42
320
3
0.96
OBL
42
320
3
0.96
Elbow
AP
48
320
8
2.56
LAT
49
320
8
2.56
OBL
46
320
8
2.56
Forearm
AP
48
320
7
2.24
LAT
49
320
7
2.24
OBL
47
320
7
2.24
Foot
AP
50
320
10
3.2
LAT
51
320
10
3.2
OBL
48
320
10
3.2
Ankle
AP
54
320
11
3.52
LAT
55
320
11
3.52
OBL
55
320
11
3.52
Tibia
AP
56
320
17
5.44
LAT
57
320
17
5.44
OBL
55
320
17
5.44
Femur
AP
48
320
8
2.56
LAT
49
320
8
2.56
OBL
47
320
8
2.56
Knee
AP
58
320
17
5.44
LAT
59
320
17
5.44
