M3 Vital Signs Monitor User Manual Specifications
- 94 -
DIA 10 mmHg ~ 215 mmHg
MAP 20 mmHg ~235 mmHg
PED mode
SYS 40 mmHg ~230 mmHg
DIA 10 mmHg ~180 mmHg
MAP 20 mmHg ~195 mmHg
NEO mode
SYS 40 mmHg ~ 135 mmHg
DIA 10 mmHg ~100 mmHg
MAP 20 mmHg ~110 mmHg
☆Alarm type
SYS, DIA, MAP, PR
☆Cuff Pressure measuring range
0 mmHg ~300 mmHg
☆Pressure resolution
1 mmHg
☆Maximum mean error
 5 mmHg
☆Maximum standard deviation
8 mmHg
Maximum measuring time of single
measurement
ADU/PED 120 s
NEO 90 s
Typical measuring period
20 s ~ 35 s (depend on HR/motion disturbance)
Overpressure protection
ADU
(297±3 ) mmHg
PED
(245±3 ) mmHg
NEO
(147±3 ) mmHg
PR
☆Measuring range
40 bpm ~240 bpm
☆Accuracy
±3 bpm or 3.5%, whichever is greater
A.2.9 SpO
2
EDAN Module
☆Measuring Range
0% ~100%
☆Adjustable range of alarm limits
0% ~100%
Resolution
1%
